LED Controllers led sensor controller 02
-
-
Large Image :LED Controllers led sensor controller 02
Product Details:
| Place of Origin: |
Guangdong, China (mainland) |
| Brand Name: |
dier lighting |
| Model Number: |
led sensor controller 02 |
| Certification: |
RoHS |
Payment & Shipping Terms:
| Minimum Order Quantity: |
100 |
| Price: |
|
| Delivery Time: |
5-7days |
| Payment Terms: |
TT or paypal or Western Union |
| Supply Ability: |
30,000pcs/month |
Detailed Product Description
-
Product Introduction:
MINI sensor controller for single color LED strip Controller adopts the most advanced PWM (Pulse Width Modulation) digital control technology for controlling constant voltage LED lamps. The function is switch on/off and dim the light by the operation of people’s hand go through the ITR sensor without touching.
-
Product Features
-
Designed for single color constant voltage LED lights in Kitchen worktop lighting/ bathroom mirror application.
-
DC12-24V, output current: 1ch*6A.
-
Stable sensitivity with ITR sensor, soft light up and down.
-
3-year warranty exclude the artificial situation of damaged or overload working.
Technical Parameters
|
Working temperature |
0-45℃ |
Supply voltage |
DC12V-24V |
|
Static power consumption |
<1W |
Sensor |
ITR |
|
Sensor range |
0-8CM |
Sensor cable |
1 meter |
|
External dimension |
L48*W26*H13 mm |
Packing size |
L100*W65*H40mm |
|
Net weight |
50g |
Gross weight |
65g |
|
PWM frequency |
490Hz |
Dimming range |
0.4%-100% |
|
Output current |
≤6A |
Max. Output power |
12V:<72W, 24V:<144W
|
Product Tag : led sensor controller,led controller , led sensor controller -HS
